Bentley S Long Wheelbase heater ducting (lwb) – schema ir OEM kodai
Electrical System · 12 pozicijų · 0 skelbimų
Schema
Paspauskite schemą, kad padidintumėte, arba poziciją lentelėje.
Pozicijos ir kodai
| Nr. | Detalė / OEM kodas | Skelb. | Kaina nuo | |
|---|---|---|---|---|
| 1 | ASSY DUCT REAR COMPARTMENT AIR CONDITIONING UD3601 | – | – | Ieškoti |
| 1 | ASSY HEATER SHUT OFF VALVE FRONT COMPARTMENT UD4273 | – | – | Ieškoti |
| 3 | ASSY LEVER HEATER SHUT OFF VALVE UD3644 | – | – | Ieškoti |
| 5 | BUTTERFLY VALVE HEATER SHUT OFF UD3641 | – | – | Ieškoti |
| 8 | END STOP HEATER SHUT OFF VALVE UD3647 | – | – | Ieškoti |
| 10 | NUT LOCK 2BA K4307Z | – | – | Ieškoti |
| 4 | PIN TAPER .0937 IN. X .625 IN. LONG K4851 | – | – | Ieškoti |
| 6 | SCREW BUTTERFLY TO SPINDLE HEATER SHUT OFF VALVE UD3642 | – | – | Ieškoti |
| 9 | SCREW CHEESE HEAD 5BA X .250 IN. LONG K1701Z | – | – | Ieškoti |
| 7 | SLEEVE END TUBE CROSS DUCT HEATER UD3643 | – | – | Ieškoti |
| 2 | SPINDLE HEATER SHUT OFF VALVE UD3639 | – | – | Ieškoti |
| 12 | WASHER SPRING 2BA K9006Z | – | – | Ieškoti |
| 11 | WASHER THICK .185 IN. I.D. UA6101Z | – | – | Ieškoti |
