BMW 3 E90 E91 GA6L45R pavara (E90 LCI 330IN52N) – schema ir OEM kodai
Individualios transmisijos dalys · 6 pozicijos · 0 skelbimų
Visos BMW 3 E90 E91 dalys →Schema
Paspauskite schemą, kad padidintumėte, arba poziciją lentelėje.
Pozicijos ir kodai
| Nr. | Detalė / OEM kodas | Skelb. | Kaina nuo | |
|---|---|---|---|---|
| 01 | Sukimo momento keitiklio komplektas 24407596064 | – | – | Ieškoti |
| 02 | O formos žiedas 24127572601 | – | – | Ieškoti |
| 03 | Fiksavimo žiedas 24127572599 | – | – | Ieškoti |
| 04 | Konverterio sandarinimo žiedų komplektas 24107581595 | – | – | Ieškoti |
| 05 | Užsukamas kamštis 24147572602 | – | – | Ieškoti |
| 06 | Aklė kamštis 24107572627 | – | – | Ieškoti |
