Bentley Azure Le Mans engine control module & fittings – schema ir OEM kodai
Engine Management · 27 pozicijos · 0 skelbimų
Schema
Paspauskite schemą, kad padidintumėte, arba poziciją lentelėje.
Pozicijos ir kodai
| Nr. | Detalė / OEM kodas | Skelb. | Kaina nuo | |
|---|---|---|---|---|
| 21 | ASSY BASE ENGINE CONTROL MODULE ENCLOSURE UT12284PA | – | – | Ieškoti |
| 27 | ASSY COOLING FAN CONTROL MODULE ENCLOSURE UD74441 | – | – | Ieškoti |
| 9 | ASSY COOLING FAN CONTROL MODULE ENCLOSURE UD74441 | – | – | Ieškoti |
| 3 | ASSY LID ENGINE CONTROL MODULE ENCLOSURE UT12251PA | – | – | Ieškoti |
| 18 | ASSY MOUNTING BRACKET CONTROL MODULES LHD UT10671PG | – | – | Ieškoti |
| 19 | ASSY MOUNTING BRACKET CONTROL MODULES RHD UT10670PG | – | – | Ieškoti |
| 12 | ASSY ONE WAY VALVE COOLING FAN CONTROL MODULE ENCLOSURE UR71288 | – | – | Ieškoti |
| 7 | CLAMP HOSE TO CONTROL MODULE HOUSING UD74830 | – | – | Ieškoti |
| 1 | CONTROL MODULE ENGINE UV36096PA | – | – | Ieškoti |
| 8 | HOSE CLIP 20/32MM SPM1983 | – | – | Ieškoti |
| 15 | HOSE CLIP 25/40MM SPM1984 | – | – | Ieškoti |
| 6 | HOSE CONTROL MODULE ENCLOSURE TO FAN UD75286 | – | – | Ieškoti |
| 16 | HOSE EVAPORATOR DUCT TO FAN CONTROL MODULE ENCLOSURE UD75106 | – | – | Ieškoti |
| 17 | MOUNTING BRACKET ENGINE CONTROL MODULE ENCLOSURE UT12163PA | – | – | Ieškoti |
| 24 | MOUNTING CLIP RELAY UD74315 | – | – | Ieškoti |
| 11 | O RING 1.234 IN. I.D. X .139 IN. UA12409R | – | – | Ieškoti |
| 14 | P CLIP UD75104 | – | – | Ieškoti |
| 23 | SCREW FLANGE HEAD NO.6 X .500 IN. LONG UA9312Z | – | – | Ieškoti |
| 10 | SCREW PAN HEAD NO.2 X .500 IN. UD75107 | – | – | Ieškoti |
| 4 | SEAL LID TO BASE CONTROL MODULE ENCLOSURE (450MM) UT12252PA | – | – | Ieškoti |
| 5 | SEAL LID TO BASE CONTROL MODULE ENCLOSURE (95MM) UT12270PA | – | – | Ieškoti |
| 25 | SEAL LID TO BASE CONTROL MODULE ENCLOSURE (95MM) UD74962 | – | – | Ieškoti |
| 13 | SETSCREW M5 X 10MM LONG UM20703Z | – | – | Ieškoti |
| 22 | SETSCREW M5 X 12MM LONG UM20704Z | – | – | Ieškoti |
| 26 | SPRING CLIP ENGINE CONTROL MODULE ENCLOSURE UT12164PA | – | – | Ieškoti |
| 2 | TEMPERATURE SENSITIVE LABEL ENGINE CONTROL MODULE UD75111 | – | – | Ieškoti |
| 20 | WASHER PLAIN M5 UM20222Z | – | – | Ieškoti |
